Speaker Terminals: What Fits What
Quick answer / TL;DR: Short answer: binding posts accept banana plugs, spade lugs or bare wire up to heavy gauges; spring clips accept bare wire only, usually up to 16 AWG; push terminals are similar but smaller. Match the wire to the terminal, prefer a mechanical termination over twisted bare strands, and check polarity at both ends.
Speaker terminals come in three practical types – binding posts, spring clips and push terminals – and each accepts a different range of wire gauges and plugs. Buying 12 AWG wire for spring clips rated at 18 AWG is the most common mismatch in domestic audio.
This is the terminal guide: the types, what each accepts, and the connection method that gives the best contact for the wire you have.
The Three Types
| The terminal | The accepts | The gauge |
|---|---|---|
| Binding post | Banana, spade, bare | Up to 12 AWG |
| Spring clip | Bare wire | Up to 16 AWG |
| Push terminal | Bare wire | Up to 18 AWG |
The terminal is the constraint, not the amplifier: heavy wire cannot be forced into a clip without losing contact area.
The Best Connection for the Wire
- Heavy wire: spade lugs or banana plugs
- Medium wire: bare wire twisted tightly
- Thin wire: bare wire, tinned if it frays
- Never: strands trimmed to fit a smaller terminal
Trimming strands to fit reduces the conductor cross-section exactly where resistance matters.
Standards and Verification
| The reference | The relevance |
|---|---|
| IEC 60268 | Audio interconnection |
| Speaker impedance | The load |
| Continuity test | Per conductor, polarity checked |
Per-SKU terminal dimensions are not provided in the knowledge base. The types are standard; measure the opening before ordering heavy wire.
Practical Notes
Mark polarity at the amplifier and at each speaker: a reversed pair is audible as thin bass and is easy to introduce when terminals are similar. Red to red, and check twice.
Real-World Applications
The spring clip system
A compact amplifier with spring clips: 16 AWG bare wire used, twisted and fully inserted – no adapters, full contact area.
The trimmed bundle
12 AWG wire trimmed to fit an 18 AWG clip: contact area lost and one channel intermittent. Spade lugs and a different amplifier input used instead.
Related reading: Choosing speaker wire gauge — blogs/news/14-gauge-speaker-wire
Related reading: Banana plug termination — blogs/news/banana-plugs
Frequently Asked Questions
What wire fits a spring clip?
Usually up to 16 AWG bare wire.
Banana plugs or bare wire?
Both work; plugs are more convenient and repeatable.
Can I trim strands to fit?
No – it reduces the conductor and creates a weak joint.
Does polarity matter?
Yes – reversed pairs thin the bass and blur the image.
